A durable, versatile commercial drone solution
DT30X
A fully integrated drone combining a fuel cell power pack and drone has excellent durability and can fly for up to 150 minutes with a maximum payload of 5kg
-
All-in-one commercial hydrogen drone boasting superior durability and flight efficiency
DT30X is the world's first all-in-one hydrogen fuel cell drone which is optimized for industrial usage. Fuel cells are located inside the drone which make them less susceptible to water. Its streamline design, optimized fuel cell powerpack, and high wind resistance gurantee effcient flight.
-
Steady fuel cell power gurantees safe flight
DMI's DM30 powerpack ensures safe flight. DM30 consisits of high performance software and harware providing stable power to hydrogen drone.
-
Steady fuel cell power gurantees safe flight
DMI's DM30 powerpack ensures safe flight. DM30 consisits of high performance software and harware providing stable power to hydrogen drone.
-
Safe control of Hydrogen drone using integrated GCS system
Integrated GCS system allows users to plan the flight path efficiently which could lead to stable flight missions.
-
Long-distance inspection and large-area surveying
DT30X has endurance of 150 minutes, which is more than 4 times of the lithitum battery drones. With long endurance and wide flight coverage, both cost and time can be significantly saved.
-
Long-distance inspection and large-area surveying
DT30X has endurance of 150 minutes, which is more than 4 times of the lithitum battery drones. With long endurance and wide flight coverage, both cost and time can be significantly saved.
-
Easy transportation & Storage
Sophisiticated packaging enables easy transportation. The dimension of the package is 980*790*570mm(L*W*H) which is suitable for transportation using SUVs.
-
Easily managagble flight missions through IoT cloud plaform
Cloud platform can be easily downloaded via Plugin, and allows users to manage flight missions using different devices.
-
Easily managagble flight missions through IoT cloud plaform
Cloud platform can be easily downloaded via Plugin, and allows users to manage flight missions using different devices.
DT30X Specs
Product |
DT30X |
Size (W x L x H) |
1,600(W) x 1,600(L) x 675(H) mm |
|---|---|---|---|
Release Date |
2023.12 |
Max Flight Speed |
18m/s |
Wheelbase |
1,600mm |
Max Speed of Ascent |
4m/s |
Weight |
20kg(with 12L Type 3 cylinder) ; 21kg(with 10.8L Type 4 cylinder) |
Max Speed of Descent |
2m/s |
System Weight |
10kg(with 12L Type 3 cylinder) ; 11kg(with 10.8L Type 4 cylinder) |
Communication Range |
10km(Standard)，10~50km(Optional) |
Max Take off Weight |
24.9kg |
Max Altitude |
3,500m |
Flight time |
150min(no payload) |
Wind Resistance |
10.8~13.8m/s |
